| 参数 | 单位 | SK40BL | SK43BL | SK45BL |
|---|---|---|---|---|
| 重量 | kg (lbs) |
320 (705) |
390 (860) |
475 (1047) |
| 长度 | mm (in) |
1340 (52.7) |
1370 (53.9) |
1480 (58.2) |
| 液压油流量 | l/min (gpm) |
130 ~ 150 (7.9 ~ 13.2) |
40 ~ 90 (10.5 ~ 23.8) |
45 ~ 80 (11.8 ~ 21.1) |
| 工作压 | kg/cm2 (psi) |
90 ~ 130 (1280 ~ 1849) |
90 ~ 130 (1280 ~ 1849) |
130 ~ 150 (1849 ~ 2133) |
| 后缸体氮气压 | kg/cm2 (psi) |
17.5 (249) |
17.5 (249) |
17.5 (249) |
| 打压频率 | bpm | 440 ~ 950 | 440 ~ 950 | 440 ~ 950 |
| 钎杆直径 | mm (in) |
68 (2.68) |
75 (2.95) |
85 (3.34) |
| 油管直径 | in | 1/2 | 1/2 | 3/4 |
| 配用车重 |
ton |
2.8 ~ 4.5 (6272 ~ 10080) |
3.5 ~ 6 (7840 ~ 13440) |
6 ~ 13 (13440 ~ 29120) |
* Specifications of Rockage hydraulic tools are subject to change without notice.
| 参数 | 单位 | SK20SL | SK30SL | SK40SL | SK43SL | ||||
|---|---|---|---|---|---|---|---|---|---|
| Top | S-type | Top | S-type | Top | S-type | Top | S-type | ||
| 重量 | kg (lbs) |
123 (271) |
228 (503) |
210 (463) |
300 (661) |
262 (578) |
356 (785) |
313 (690) |
386 (851) |
| 长度 | mm (in) |
1347 (53) |
1495 (58.8) |
1596 (62.8) |
1779 (70) |
||||
| 液压油流量 | l/min (gpm) |
25 ~ 40 (6.6 ~ 10.5) |
30 ~ 50 (7.9 ~ 13.2) |
30 ~ 50 (7.9 ~ 13.2) |
40 ~ 90 (10.5 ~ 23.8) |
||||
| 工作压力 | kg/cm2 (psi) |
80 ~ 110 (1137 ~ 1564) |
90 ~ 130 (1280 ~ 1849) |
90 ~ 130 (1280 ~ 1849) |
90 ~ 130 (1280 ~ 1849) |
||||
| 后缸体氮气压 | kg/cm2 (psi) |
14 ~ 17 (199 ~ 242) |
17.5 (249) |
17.5 (249) |
17.5 (249) |
||||
| 打击频率 | bpm | 700 ~ 1000 | 700 ~ 950 | 440 ~ 950 | 400 ~ 950 | ||||
| 钎杆直径 | mm (in) |
45 (1.77) |
53 (2.08) |
68 (2.68) |
75 (2.95) |
||||
| 油管直径 | in | 1/2 | 1/2 | 1/2 | 1/2 | ||||
| 配用车重 | ton (lbs) |
1.7 ~ 3.5 (3808 ~ 7840) |
2.5 ~ 4 (5600 ~ 8960) |
2.8 ~ 4.5 (6272 ~ 10080) |
3.5 ~ 6 (7840 ~ 13440) |
||||
* Specifications of Rockage hydraulic tools are subject to change without notice.
