| Model | Unit | SKR-06 | SKR-08 | SKR-10 | SKR-17 | SKR-20 |
|---|---|---|---|---|---|---|
| A | mm (in) |
390 (15.35) |
465 (18.3) |
515 (20.28) |
550 (21.65) |
575 (22.64) |
| B | mm (in) |
540 (21.26) |
665 (26.18) |
735 (28.94) |
800 (31.5) |
825 (32.48) |
| C | mm (in) |
890 (35.04) |
1245 (49.02) |
1370 (53.94) |
1530 (60.24) |
1550 (61.02) |
| D | mm (in) |
55 ~ 65 (2.17 ~ 2.55) |
70 ~ 80 (2.76 ~ 3.15) |
80 ~ 90 (3.15 ~ 3.54) |
90 ~ 100 (3.54 ~ 3.94) |
100 ~ 120 (3.94 ~ 4.72) |
| D' | mm (in) |
55 ~ 65 (2.17 ~ 2.55) |
70 ~ 80 (2.76 ~ 3.15) |
80 ~ 90 (3.15 ~ 3.54) |
90 ~ 100 (3.54 ~ 3.94) |
100 ~ 120 (3.94 ~ 4.72) |
| E | mm (in) |
240 ~ 300 (9.45 ~ 11.81) |
300 ~ 350 (11.81 ~ 13.78) |
360 ~ 420 (14.17 ~ 16.54) |
400 ~ 450 (15.74 ~ 17.72) |
440 ~ 500 (17.32 ~ 19.68) |
| F | mm (in) |
390 (15.35) |
520 (20.47) |
600 (23.62) |
470 (18.507) |
680 (26.77) |
| Weight | kg (lbs |
120 ~ 150 | 210 ~ 250 | 350 ~ 410 | 520 ~ 600 | 650 ~ 750 |
| Applicable Excavator |
ton (lbs) |
11 ~ 15 | 16 ~ 23 | 23 ~ 30 | 31 ~ 40 | 41 ~ 50 |
